Promoter Info

Total Square Feet:

• Floor: 17,000
• Concourse: 17,830
• Upper Lobby: 7,585
• Lower Lobby: 3,845

The facility consists of:

• 10 locker/dressing rooms
• Athletic training facility
• Meeting/conference/family room
• Offices
• Concessions
• On-site parking
• Flexible arena configurations

Download Lower Level Map

A portable, insulated arena deck covering is provided by Space Age Synthetics.

• Ice Level Loading Door: 1 ice level access door, 15’ H x 18’ W
• Loading Ramp Grade: 8%

Bus and truck parking is available along 30th Ave S next to load-in. This street is closed to the public during events/concerts. We have 3 RV-style hook ups to plug into.

Download Parking Map

• Concourse: 1 door in northwest corner on main concourse level, 7.5’ H x 8’ W
• Ice Level: 1 ice level access door, 15’ H x 14’ W
• Arena Floor: 1 arena floor access area clearance, 11.5’ H x 9’ W
• Lower Lobby: Front entrance access to lower lobby, 7.5’ H x 6.5’ W

• 2 x 400 Amp and 2 x 200 Amp / 3 Phase Disconnects located backstage
• 1 x 200 Amp panel in NW corner of event level
• 1 x 200 Amp panel in NE corner of event level

• Combination of QSC and JBL VRX Series speakers throughout the concourses and over the surface, allowing for 100 dB to all seats and 100% building coverage.
• Equipped with:
  • 2 hard-wired microphones
  • 4 wireless microphones
  • 16 channel audio mixer
  • Audio XLR and video connections (SDI & Triax) on media deck, truck dock, penalty box, and production room

• LED lighting above arena bowl provides instant lighting and black-out conditions. Fluorescents rate at 600 lux.
• LED bars above arena bowl can be programmed to any color for walk-in or light show.
• LED sports lighting around the main arena increases lighting to 1500 lux.

Scheels Arena is equipped with:

• Center-hung video board (18.9’ W x 12.6’ H, 960 pixels W x 640 pixels H, 6mm pixel pitch)
• Two Panasonic video boards (10’ W x 18’ H) on the north and south ends of the ice area
• 2.5’ x 200’ fascia
• Two smaller fascia's (3’ x 55’)
• In-house channel (Channel 98) feeds live video to all televisions in the building
• Ability to interface with outside equipment

• 3 Professional Cameras – Black Magic Ursa Broadcast (no complex, triax, tally, or CCUs)
• 12-input Video Switcher (one framesync, no MMEs or DVE)
• Multi-media server/character generator, single channel
• Replay machines – 4 channel Zeplay
• Headsets with 4-pin connectors (clear com system)
• Six hard-wired locations – coax video cable, intercom, and outlet for power
• Minimal audio mixing capabilities

Bowl Area Media:

• Long fascia board: 3904 W x 48 H (Export as png,  jpg, or mp4 30fps)
• Short fascia board: 1664 W x 64 H (Export as png,  jpg, or mp4 30fps)
• Video board graphic: 720 W x 486 H (Export as PNG or TIF.)
• Video board: 1280 W x 720 H. Audio 48khz. Export as MOV (Pro-Res 422) or MP4 (h.264) and 29.97 fps.

Lobby Televisions:

(For event information, sponsors, etc.)

• Video containers: 1280 W x 720 H. Export as MOV (Pro-Res 422 or h.264) or MP4 (h.264)
• Audio codecs: Plays from a computer. Export as AAC, MP3, or LPCM.
• Photo images/slides: 1280 W x 720 H. Export as JPEG, BMP, PNG, or GIF.
